Gold Series High Vacuum Dust Collector

Home > Products > Dust Collectors > Gold Series High Vacuum Dust Collector

Gold Series High Vacuum Dust Collector

    The GSHV Gold Series High Vacuum can be used in applications up to 17 in Hg or 8 psi positive pressure. Common applications include central vacuum systems, positive or negative product receivers and high pressure bin vents.

    Standard Features and Benefits

    • Heavy duty 10 and 7 guage construction.
    • Vessel strength: 17 in Hg vacuum, 8 psi positive pressure (without explosion vent).
    • Flanged, tangential inlet minimizes dust contacting the filters.
    • Two models available: -GS2HV ( 2- cartridge design)  -GS4HV (4-cartridge design)
    • Can be configured as a stand-alone dust collector or without hopper and support structure for bin vent applications.
    • Pulse-cleaning system includes field-mountable, solid state control panel.
    • HemiPleat® Gold Cone™ filter cartridges with double seal gaskets and separator bead that ensures uniform pleat spacing of media.


    • Horizontal explosion vent.
    • Bag-in bag-out filter access door for pharmaceutical/hazardous dusts.
    • Continuous liner discharge for pharmaceutical hazardous dusts.
    • Discharge collection devices such as a 55-gallon drum or self-dumping hopper

    Contact us for pricing »
